Name: DMX512 Signal Amplifier Distributor 8 Channels 100~240V
Brand: BOGDAN LED
SKU: 9000000339170
Price: 5400.0 THB
Availability: InStock

This is your starter site, a single page online storefront. All of the images and text on this page can be changed to personalize the site for brand and to communicate your unique story to your customers.

DMX512 Signal Amplifier Distributor 8 Channels 100~240V

SKU 9000000339170

฿5 400.00

In stock

Quantity:

Product Details

SKU: 9000000339170

Brand: BOGDAN LED

Input Voltage: 100~240V DC

Weight: 3.00 kg

Product Type : DMX512 LED Controller

Brand: BOGDAN LED

Product model name: Signal Amplifier Distributor 8 Channels

Technical parameters
Working temperature: -20-60℃
Input voltage: AC 100 ~ 240V50～60Hz
Rated power: 7W
Input signal：8 channel DMX512 signal, the output port can be connected to 32 equipments mostly.
The isolation voltage between input/output interface: > 1000V
Cascade quantity: can cascade 16 Pcs signal amplifier mostly.
Net weight: 1.95kg
DMX128 signal distributor is one series of DMX signal distributor, is specially used for amplifying DMX512 digital lighting control signal and 8 channels allocation output. The input/output interface adopts high voltage isolation technology, applied to amplify DMX512 signal transmission in the short distance,
as well as the using occasion where output/input interfaces need to be complete electrical isolation. Due to the independent isolation between input/output interfaces, it can avoid burning precision digital light console by the problem of the controlling circuit, decoder, computer light, silicon box and so on,
to ensure the safe operation of digital lighting control, and also ensure DMX signal can normal transfer to all kinds of lighting equipment, so as to improve reliability for the whole digital lighting control system
