Product type : Controller

Brand: BOGDAN LED

Product Name : LED Controller Model: LT-209

• Product Features:
• The LT-209 music controller supports matrix mode and linear mode. Matrix mode based on the input sound or the received sound/rhythm of the music produces the corresponding geometric LED color to achieve the effect of skipping. It is considered as a music mode LED screen, using a single voice data to control the brightness of the LED lamps and lamps of all pixels.
• (It can be controlled based on the LED driver IC for LED lamps such as
• LPD6803, LPD1101, D705, UCS6909, UCS6912, LPD8803, LPD8806, TM1803, TM1804, TM1809, TM1812, UCS1903 , UCS1909, UCS1912, UCS2903, TLS3001, TLS3002, WS2809, WS2812, UCS1903 , UCS1909, UCS1912, UCS2903, TLS3001, TLS3002, WS2809, WS281, WS2803, WS12, Max Pixels (supports 112803, WS12, WS12, pixel pixels)
• Support audio line input audio and built-in microphone input with live music. The sensitivity of the audio receiver can be adjusted.
• There are built-in 16 kinds of transition modes, including black effect, 13 static colors and two DMX transition effects, and the DMX transition effect is also affected by Control the music as well.
• Performance features
• LCD screen
• Applicable to light control mode of pattern matrix and linear model.
• Support audio line input and built-in microphone
• Sound pick-up sensitivity can be adjusted.
• 16 built-in lighting effects
• Product parameters
• Working voltage : DC12V
• Power Consumption: ＜2W
• Output signal : SPI(TTL)
• Working mode : 16 modes
• Number control : 1024 pixels
• Working temperature: -30℃～65℃
• Size : L163×W125×H40mm
• Weight : 760g/0.76kg
