The upper PC has a built-in programmable timer for controlling load output over multiple times. Customers can customize their desired schedule mode via the upper PC, and then download the necessary schedule to the controller via the USB port. In addition to the schedule mode editing function, the upper PC can also set the time for the controller due to the upper host's synchronous clock function. If users want to view the schedule mode results after editing, they can use the upper PC's quick delete function. Since the upper PC does not have a delete function, the mode name display area will remain empty until you perform a delete operation. This controller can control up to five channels of LED light change effects and can be used in applications such as plant lighting, advertising light boxes, stage performances, home decoration, etc.

..Technical Parameters

Operating temperature: -20-60°C

Voltage: DC12-24V

Static power: <0.5W

Net weight: 210g

Gross weight: 350g

External dimensions: 150mm * 78.5mm * 26mm

Output: 5 channels

Maximum load current: 20A

Output: Five CMOS open-loop drain outputs

Connection mode: Common anode

Controller output frequency: 600 Hz
